Driveman720 specifications
Type | Full time recording Drive Recorder |
Image sensor | CMOS 5 mega pixel |
Video Quality | 1280 x 720 progressive Hi-Def |
File type | H.264 MOV file |
REC trigger | Ignition key ON manual overide |
REC system | Full time recording, Endless recording, when memory becomes Full the oldest file to be erased and replaced by new file. |
Storage Media | SDHC memory card |
Output | HDMI |
Michophone | Built-in rear side of Driveman |
Display | Built-in LCD 2.5 inch color |
Clock | Date/Time indication. Super capacitor requires ignition key ON once a week for clock power. |
Internal Battery | None |
Mount | Window shield mount by adhesive tape that cures after 24 hr. |
Poewr supply | Accessory terminal of car and ground. Mostly connected to rear of audio unit. Cigar Socket adaptor option. |
Environmental concern: | RoHS standard WEEE standard cleared. |
Dimensions | 70 x 105 x 35mm exclude bracket |
Weight | approx. 100 grams |
Supplied with | Driveman body, Car mount harness, Mount bracket, Adhesive tape, HDMI cable, AC adaptor, Instruction. |
For installation, ask car service station, or use optional Cigar Socket adaptor.
Important - SDHC card
Recorded image is endless by over write files. Important file should be copied to PC or exchanged other SDHC card.
Up to 32GB SDHC card can be used with Driveman, although poor card quality may not do the job.
Card has rewrite life time. Not parmanent. Use new one when time comes.
SDHC card is formatted when purchased as best performing condition. Do not format by PC unless best performing style is known.
If other image file created by other than Driveman in a same SDHC card, function and operation of Driveman may take longer time than usual.
Old standard SD card may not work properly with Driveman.
Download Page
Japanese Instruction | |
Instruction | |
Installation instruction :P1 |
|
Installation instruction :P2 | |
Playback by Driveman | |
Literature Front Page | |
Literature Rear Page |
DRIVEMAN@F/W update Standard Operating Procedure
Step.1 Copy the firmware file sd dr100.bin onto SD and insert the SD card to DRIVEMAN.
Step.2 Enter the Playback mode after power on.
Step.3 First Press and hold "Up" button ,then Press and hold the "Record" simultaneously.
Step.4 While DRIVEMAN is upgrading, the screen will appear "Updating" .
Step 5 After the "Updating" is disappear , upgrading is finish ! Please Power on again.
Product Catalog Number | 2010/08 | |
Driveman 720 kit | 720DM | Basic Kit (A) |
Driveman body | 720BD | Included in (A) |
AC adaptor | 720AC | Included in (A) |
Adhesive tape | 720TP | Included in (A) |
Bracket | 720BR | Included in (A) |
Car mount harness | 720DC | Included in (A) |
HDMI cable | 720HDMI | Included in (A) |
Instruction | 720IN | Included in (A) |
SDHC card 4GB | SDC04 | Option |
Cigar Socket Adaptor | 720CSA | Option |
